SAS Companion for the OS/2 Environment

Using Named Pipes

The named pipes capability is one of the most powerful tools available in the SAS System under OS/2 for communicating with other applications. The named pipes feature enables bidirectional data or message exchange between applications that are on the same machine or applications that are on separate machines across a network. Communication Using Named Pipes illustrates these two basic methods of communication.

Communication Using Named Pipes

[IMAGE]

The applications can be SAS sessions or other OS/2 applications. For example, using a named pipe you can use the PRINTTO procedure to direct the results from SAS procedures to another OS/2 application. Therefore, you can have either multiple SAS sessions that communicate with each other or one SAS session that communicates with another OS/2 application.

Whether you are communicating between multiple SAS sessions or between a SAS session and another OS/2 application that supports named pipes, the pipes are defined in a client/server relationship. One process is defined as the server, while one or more other processes are defined as clients. In this configuration, you can have multiple clients send data to the server or the server send data to the various clients. Named pipes enable you to coordinate processing between the server and clients by using various options.

Named Pipe Syntax

You can use a named pipe anywhere that you use a fileref in the SAS System. To use a named pipe, issue a FILENAME statement with the following syntax:

FILENAME fileref NAMEPIPE 'pipe-specification' <named-pipe-options>;

You can use the following arguments with this form of the FILENAME statement:

fileref

is any valid fileref as described in Referencing External Files.

NAMEPIPE

is the device-type keyword that tells the SAS System that you want to use a named pipe.

pipe-specification

is the name of the pipe.

This argument has two mutually exclusive forms:

\\.\PIPE\pipe-name: indicates that you are establishing a pipe on a single PC or defining a server pipe across a network. The pipe-name argument specifies the name of the pipe.
\\server-name\PIPE\pipe-name: indicates that you are establishing a client pipe over a network named-pipe server. Remember to include the double backslash (\\) in this situation. The pipe-name argument specifies the name of the client pipe. The server-name argument specifies the name of the named-pipe server.

named-pipe-options

can be any of the following. The default value is listed first:

SERVER | CLIENT

indicates the mode of the pipe. SERVER is the default.

BLOCK | NOBLOCK

indicates whether the client or server is to wait for data to be read if no data are currently available. BLOCK indicates to wait, and it is the default. NOBLOCK indicates not to wait; control is returned immediately to the program if no data are available in the pipe. Writing to the pipe always implies BLOCK.

BYTE | MESSAGE

indicates the type of pipe. BYTE is the default. The difference between a BYTE pipe and a MESSAGE pipe is that a MESSAGE pipe includes an encoded record length, whereas a BYTE pipe does not.

RETRY=seconds

indicates the amount of time that the client or server should wait to establish the pipe. The minimum value for seconds is 10. This is also the default. This option allows time for synchronization of the client and server.

There are two values for the seconds argument that indicate special cases:

-2 indicates the client should wait the amount of time that is defined by the server's RETRY= option. If this option is used, the SERVER option must always be active or the pipe connection fails.

-1 indicates the client or server should wait indefinitely for the pipe connection.

EOFCONNECT

is valid only when you are defining the server, and it indicates that if an end-of-file (EOF) character is received from a client, the server should try to connect to the next client.

All of these options are consistent with the terminology that is used in OS/2 programmers' reference guides.

Using the CALL RECONNECT Routine

There is a special SAS CALL routine that works with named pipes. The CALL RECONNECT routine enables the server to disconnect the current client and try to connect to the next available client. Normally, the pipe is terminated when the client side of the pipe sends an end-of-file character to the server. To break the pipe connection at any time, the server SAS session can issue a CALL RECONNECT statement. For an example of this routine, see The CALL RECONNECT Routine.

Using Named Pipes in SCL

To establish named pipes by using SCL code, you must use the FOPEN function to open a file (or pipe) before you can access it. In doing so, you must specify the appropriate open mode for both the client and server applications so that the two can communicate over the pipe. Here is a summary of the different modes that you can use:

If the server accesses the pipe as... then the client must access the pipe as...

I (input) O (output)

O (output) S (sequential)

U (update) O (output) or S (sequential)

If the server accesses the pipe as...	then the client must access the pipe as...
I (input)	O (output)
O (output)	S (sequential)
U (update)	O (output) or S (sequential)

Named Pipe Examples

The best way to understand named pipes is to examine several different examples that illustrate their use. In most of the examples in this section, the named pipe is established between two SAS sessions. However, named pipes work between the SAS System and other applications that support named pipes.

Simple Named Pipes: One Client Connected to One Server

The simplest named pipe configuration is one server connected to one client, as shown in One Server Connected to One Client.

One Server Connected to One Client

[IMAGE]

In the following example, a named pipe that is called WOMEN is established between two SAS sessions. The server SAS session selectively sends data to the client SAS session. You can start the server or the client first; one waits 30 seconds for the other to connect.

In the first SAS session, create a named pipe as a server:

   /* Creates a pipe called WOMEN, acting */
   /* as a server. The server waits 30    */
   /* seconds for a client to connect.    */
filename women namepipe '\\.\pipe\women'
         server retry=30;
   /* This code writes three records into */
   /* the named pipe called WOMEN.        */
data class;
   input name $ sex $ age;
   file women;
   if upcase(sex)='F' then
      put name age;
   cards;
MOORE M 15
JOHNSON F 16
DALY F 14
ROBERTS M 14
PARKER F 13
;

In the second SAS session, you can use SAS statements to exchange data between the two SAS sessions. For example, you can submit the following program from the client session:

   /* Creates a pipe called WOMEN, acting */
   /* as a client.  The client waits 30   */
   /* seconds for a server to connect.    */
filename in namepipe '\\.\pipe\women' client
         retry=30;
data female;
   infile in;
   input name $ age;
proc print;
run;

The following program is another example of a single client and server. This example illustrates how to use the PRINTTO procedure to direct results from the SUMMARY procedure to another OS/2 application. The example uses a named pipe called RESULTS:

filename results namepipe '\\.\pipe\results'
     server retry=60;
proc printto print=results new;
run;
proc summary data=monthly;
run;

One Server Connected to Several Clients

You can choose to have one server connected to several clients. In this case, the named pipe configuration looks like that shown in One Server Connected to Several Clients.

One Server Connected to Several Clients

[IMAGE]

In this configuration, the data connection is initially between the server and the first client. When this connection is terminated, the server connects to the second client, and so on. The connection can return to the first client after the last client's connection is broken if your program is set up to do so.

You must use the EOFCONNECT option to cause the connection to move properly from one client to the next. The following is an example of using the EOFCONNECT option with one server SAS session and two clients. The clients can be on the same PC or on a PC that is connected across a network.

In the first SAS session, submit the following statements:

   /* Creates a pipe called SALES, acting  */
   /* as a server. The server waits 30     */
   /* seconds for a client to connect.     */
   /* After the client has disconnected,   */
   /* this server SAS session tries to     */
   /* connect to the next available client */
filename daily namepipe '\\.\pipe\sales'
         server eofconnect retry=30;
   /* This program reads in the daily     */
   /* sales figures sent from each client.*/
data totsales;
   infile daily;
   input dept $ item $ total;
run;

In the second SAS session, submit the following statements:

  /* Creates a pipe called SALES, acting   */
  /* as a client. The client waits forever */
  /* for a server to connect. After the    */
  /* first client has disconnected, the    */
  /* second client connects with the server.*/
  /* The first client is the TOYS dept.    */
filename dept1 namepipe '\\.\pipe\sales'
         client retry=-1;
data toys;
   input item $ total;
   dept='TOYS';
   file dept1;
   put dept item total;
   cards;
DOLLS 100
MARBLES 10
BLOCKS 50
GAMES 60
CARS 40
;
  /* The second client is the SPORTS dept.*/
  /* These data could come from a separate */
  /* SAS session.                          */
filename dept2 namepipe '\\.\pipe\sales'
         client retry=-1;
data sports;
   input item $ total;
   dept='SPORTS';
   file dept2;
   put dept item total;
   cards;
BALLS 30
BATS 65
GLOVES 15
RACKETS 75
FISHING 20
TENTS 115
HELMETS 45
;

The NOBLOCK Option

The following example uses the NOBLOCK option to specify that the program should continue to execute if no data are available when the pipe is read. If the default value of BLOCK had been used, then the pipe would wait indefinitely until data were found in the pipe. The EOFCONNECT option is also used to tell the server that when a client sends an end-of-file (EOF) character, the server should try to connect with a new client. The RETRY= option tells the server to look for any new clients for 20 seconds while the client waits indefinitely on a server. The clients can be on the same PC or on a PC that is connected across a network. A server connects to one client at a time, and the clients queue in a serial order waiting to connect to the server.

First, submit the following statements in the SAS server session:

   /* Defines a named pipe called LINE.   */
   /* Use the NOBLOCK option to specify   */
   /* that if no data are available when  */
   /* the read is performed, then continue.*/
   /* Use the EOFCONNECT option to tell   */
   /* the server to try to connect with a */
   /* new client if an end-of-file is     */
   /* encountered. Use the RETRY= option  */
   /* to tell the server to look for any  */
   /* new clients for 20 seconds.         */
filename data namepipe '\\.\pipe\line' server
         noblock eofconnect retry=20;
   /* This DATA step reads in all data  */
   /* from any clients connected to the */
   /* named pipe called LINE.           */
data all;
   infile data length=len;
   input @;
      /* If the length of the incoming  */
      /* record is 0, then no data were */
      /* found in the pipe; otherwise,  */
      /* read the incoming data.        */
   if len ne 0 then
      do;
         input machine $ width weight;
         output;
      end;
run;
proc print;
run;

Each of the following client DATA steps can be executed on several different PCs that are connected across a network:

   /* Defines a named pipe called LINE.  */
   /* The RETRY= option is set such that */
   /* the clients wait forever until a   */
   /* server is available                */
   /* (that is, RETRY=-1).               */
   filename data namepipe '\\.\pipe\line'
            client retry=-1;
   /* This is information from the */
   /* first machine/client.        */
data machine1;
   file data;
   input width weight;
   machine='LINE_1';
   put machine width weight;
   cards;
5.3 18.2
3.2 14.3
4.8 16.9
6.4 20.8
4.3 15.4
6.1 19.5
5.6 18.9
;
   /* This is information from the */
   /* second machine/client.       */
data machine2;
   file data;
   input width weight;
   machine='LINE_2';
   put machine width weight;
   cards;
4.3 17.2
5.2 18.4
6.8 19.9
3.4 14.5
5.3 18.6
4.1 17.1
6.6 19.5
;

The CALL RECONNECT Routine

The following example demonstrates how to set up a named pipe server to establish a connection with two clients. (For this example, you need three active SAS sessions.) In this example, the CALL RECONNECT routine reconnects to the next client on the named pipe if at least 30 seconds have passed since the previous client has sent any data. Each client is a data entry operator that sends data to the server SAS session.

In the server SAS session, submit the following statements:

filename data namepipe '\\.\pipe\orders'
         server noblock eofconnect retry=30;
data all;
   infile data length=len missover;
   input @;
      /* If the length of the incoming  */
      /* record is 0, then no data were */
      /* found in the pipe; otherwise,  */
      /* read the incoming data         */
   if len ne 0 then
      do;
         input operator $ item $ quantity $;
         if item='' or quantity='' then
            delete;
         else
            output;
         put operator= item= quantity=;
      end;
      /* If no data are being transmitted,*/
      /* try reconnecting to the next     */
      /* available client.                */
   else
      do;
            /* Use the named pipe fileref */
            /* as the argument of */
            /* CALL RECONNECT. */
         call reconnect('data');
      end;
   run;

In the second SAS session, which is the first data entry operator, submit the following statements:

filename data namepipe '\\.\pipe\orders'
         client retry=-1;
data entry1;
   if _n_=1 then
     do;
        window entry_1
         #1 @2 'ENTER STOP WHEN YOU ARE FINISHED'
         #3 @5 'ITEM NUMBER - ' item $3.
         #5 @5 'QUANTITY - ' quantity $3.;
     end;
     do while (upcase(_cmd_) ne 'STOP');
        display entry_1;
        file data;
        put 'ENTRY_1' +1 item quantity;
        item='';
        quantity='';
     end;
   stop;
run;

In the third SAS session, which is the second data entry operator, submit the following statements:

filename data namepipe '\\.\pipe\orders'
         client retry=-1;
data entry2;
   if _n_=1 then
     do;
       window entry_2
        #1 @2 'ENTER STOP WHEN YOU ARE FINISHED'
        #3 @5 'ITEM NUMBER - ' item $3.
        #5 @5 'QUANTITY - ' quantity $3.;
     end;
     do while (upcase(_cmd_) ne 'STOP');
        display entry_2;
        file data;
        put 'ENTRY_2' +1 item quantity;
        item='';
        quantity='';
     end;
   stop;
run;
