The NLP Procedure

Example 5.6: Maximum Likelihood Weibull Estimation

Two-Parameter Weibull Estimation

The following data are taken from Lawless (1982, p.193) and represent the number of days it took rats painted with a carcinogen to develop carcinoma. The last 2 observations are censored data from a group of 19 rats:

 title 'Lawless (1982): 2-Parameter Weibull MLE';
 data pike;
   input days cens @@;
   datalines;
     143  0  164  0  188  0  188  0
     190  0  192  0  206  0  209  0
     213  0  216  0  220  0  227  0
     230  0  234  0  246  0  265  0
     304  0  216  1  244  1
     ;

Suppose that you want to show how to compute the maximum likelihood estimates of the scale parameter \sigma (\alpha in Lawless), the shape parameter c (\beta in Lawless), and the location parameter \theta (\mu in Lawless). The observed likelihood function of the three-parameter Weibull transformation (Lawless 1982, p.191) is

L(\theta,\sigma,c) = \frac{c^m}{\sigma^m}
 \prod_{i \in D} (\frac{t_i - \theta}{\sigma})^{c-1}
 \prod_{i=1}^p \exp (-(\frac{t_i - \theta}{\sigma})^c)

and the log likelihood is

l(\theta,\sigma,c) = m \log c - mc \log \sigma
 + (c-1) \sum_{i \in D} \log(t_i - \theta)
 - \sum_{i=1}^p (\frac{t_i - \theta}{\sigma})^c

The log likelihood function can only be evaluated for \sigma \gt 0, c > 0, and \theta \lt \min_i t_i. In the estimation process, you must enforce these conditions using lower and upper boundary constraints. The three-parameter Weibull estimation can be numerically difficult, and it usually pays off to provide good initial estimates. Therefore, you first estimate \sigma and c of the two-parameter Weibull distribution for constant \theta=0.You then use the optimal parameters \hat{\sigma} and \hat{c}as starting values for the three-parameter Weibull estimation.

Although the use of an INEST= data set is not really necessary for this simple example, it illustrates how it is used to specify starting values and lower boundary constraints:

 data par1(type=est);
   keep _type_ sig c theta;
     _type_='parms'; sig = .5;
          c = .5;    theta = 0;   output;
     _type_='lb';    sig = 1.0e-6;
          c = 1.0e-6; theta = .;  output;

The following PROC NLP call specifies the maximization of the log likelihood function for the two-parameter Weibull estimation for constant \theta=0:

 proc nlp data=pike tech=tr inest=par1 outest=opar1
      outmodel=model cov=2 vardef=n pcov phes;
   max logf;
   parms sig c;
   profile sig c / alpha = .9 to .1 by -.1 .09 to .01 by -.01;

   x_th = days - theta;
   s    = - (x_th / sig)**c;
   if cens=0 then s + log(c) - c*log(sig) + (c-1)*log(x_th);
   logf = s;
 run;

After a few iterations you obtain the following solution.

Output 5.6.1: Optimization Results

PROC NLP: Nonlinear Maximization

Optimization Results
Parameter Estimates
N Parameter Estimate Approx
Std Err
t Value Approx
Pr > |t|
Gradient
Objective
Function
1 sig 234.318611 9.645908 24.292021 9.050475E-16 1.3372182E-9
2 c 6.083147 1.068229 5.694611 0.000017269 -7.859277E-9


Since the gradient has only small elements and the Hessian is negative definite (has only negative eigenvalues), the solution defines an isolated maximum point.

Output 5.6.2: Hessian Matrix at x*

PROC NLP: Nonlinear Maximization

Hessian Matrix
  sig c
sig -0.011457556 0.0257527577
c 0.0257527577 -0.934221388


The square roots of the diagonal elements of the approximate covariance matrix of parameter estimates are the approximate standard errors (ASE's).

Output 5.6.3: Covariance Matrix

PROC NLP: Nonlinear Maximization

Covariance Matrix 2: H = (NOBS/d)
inv(G)
  sig c
sig 93.043549863 2.5648395794
c 2.5648395794 1.141112488


The following confidence limits correspond to the \alpha values in the PROFILE statement.

Output 5.6.4: Confidence Limits

PROC NLP: Nonlinear Maximization

Wald and PL Confidence Limits
N Parameter Estimate Alpha Profile Likelihood Confidence
Limits
Wald Confidence Limits
1 sig 234.318611 0.900000 233.111324 235.532695 233.106494 235.530729
1 sig . 0.800000 231.886549 236.772876 231.874849 236.762374
1 sig . 0.700000 230.623280 238.063824 230.601846 238.035377
1 sig . 0.600000 229.292797 239.436639 229.260292 239.376931
1 sig . 0.500000 227.855829 240.935290 227.812545 240.824678
1 sig . 0.400000 226.251597 242.629201 226.200410 242.436813
1 sig . 0.300000 224.372260 244.643392 224.321270 244.315953
1 sig . 0.200000 221.984557 247.278423 221.956882 246.680341
1 sig . 0.100000 218.390824 251.394102 218.452504 250.184719
1 sig . 0.090000 217.884162 251.987489 217.964960 250.672263
1 sig . 0.080000 217.326988 252.645278 217.431654 251.205569
1 sig . 0.070000 216.708814 253.383546 216.841087 251.796136
1 sig . 0.060000 216.008815 254.228034 216.176649 252.460574
1 sig . 0.050000 215.199301 255.215496 215.412978 253.224245
1 sig . 0.040000 214.230116 256.411041 214.508337 254.128885
1 sig . 0.030000 213.020874 257.935686 213.386118 255.251105
1 sig . 0.020000 211.369067 260.066128 211.878873 256.758350
1 sig . 0.010000 208.671091 263.687174 209.472398 259.164825
2 c 6.083147 0.900000 5.950029 6.217752 5.948912 6.217382
2 c . 0.800000 5.815559 6.355576 5.812514 6.353780
2 c . 0.700000 5.677909 6.499187 5.671537 6.494757
2 c . 0.600000 5.534275 6.651789 5.522967 6.643327
2 c . 0.500000 5.380952 6.817880 5.362638 6.803656
2 c . 0.400000 5.212344 7.004485 5.184103 6.982191
2 c . 0.300000 5.018784 7.225733 4.975999 7.190295
2 c . 0.200000 4.776379 7.506166 4.714157 7.452137
2 c . 0.100000 4.431310 7.931669 4.326067 7.840227
2 c . 0.090000 4.382687 7.991457 4.272075 7.894220
2 c . 0.080000 4.327815 8.056628 4.213014 7.953280
2 c . 0.070000 4.270773 8.129238 4.147612 8.018682
2 c . 0.060000 4.207130 8.211221 4.074029 8.092265
2 c . 0.050000 4.134675 8.306218 3.989457 8.176837
2 c . 0.040000 4.049531 8.418782 3.889274 8.277021
2 c . 0.030000 3.945037 8.559677 3.764994 8.401300
2 c . 0.020000 3.805759 8.749130 3.598076 8.568219
2 c . 0.010000 3.588814 9.056751 3.331572 8.834722


Three-Parameter Weibull Estimation

You now prepare for the three-parameter Weibull estimation by using PROC UNIVARIATE to obtain the smallest data value for the upper boundary constraint for \theta. For this small problem, you can do this much more simple by just using a value slightly smaller than the minimum data value 143.

 /* Calculate upper bound for theta parameter */
 proc univariate data=pike noprint;
   var days;
   output out=stats n=nobs min=minx range=range;

 data stats;
   set stats;
   keep _type_ theta;

   /* 1. write parms observation */
   theta = minx - .1 * range;
   if theta < 0 then theat = 0
   _type_ = 'parms'; output;

   /* 2. write ub observation */
   theta = minx * (1 - 1e-4);
   _type_ = 'ub'; output;

The data set PAR2 specifies the starting values and the lower and upper bounds for the three-parameter Weibull problem:

 proc sort data=opar1;
   by _type_;

 data par2(type=est);
   merge opar1(drop=theta) stats;
   by _type_;
   keep _type_ sig c theta;
   if _type_ in ('parms' 'lowerbd' 'ub');

The following PROC NLP call uses the MODEL= input data set containing the log likelihood function that was saved during the two-parameter Weibull estimation:

 proc nlp data=pike tech=tr inest=par2 outest=opar2
      model=model cov=2 vardef=n pcov phes;
   max logf;
   parms sig c theta;
   profile sig c theta / alpha = .5 .1 .05 .01;
 run;

After a few iterations, you obtain the following solution.

Output 5.6.5: Optimization Results

PROC NLP: Nonlinear Maximization

Optimization Results
Parameter Estimates
N Parameter Estimate Approx
Std Err
t Value Approx
Pr > |t|
Gradient
Objective
Function
1 sig 108.382717 32.573369 3.327341 0.003540 -1.127807E-9
2 c 2.711477 1.058759 2.560996 0.019108 -0.000000175
3 theta 122.025956 28.692412 4.252900 0.000430 -2.427323E-8


From inspecting the first- and second-order derivatives at the optimal solution, you can verify that you obtained an isolated maximum point.

Output 5.6.6: Hessian Matrix

PROC NLP: Nonlinear Maximization

Hessian Matrix
  sig c theta
sig -0.010639974 0.0453887849 -0.010033749
c 0.0453887849 -4.078687937 -0.083026332
theta -0.010033749 -0.083026332 -0.014752091


The square roots of the diagonal elements of the approximate covariance matrix of parameter estimates are the approximate standard errors.

Output 5.6.7: Covariance Matrix

PROC NLP: Nonlinear Maximization

Covariance Matrix 2: H = (NOBS/d) inv(G)
  sig c theta
sig 1061.0226092 29.92616134 -890.0900345
c 29.92616134 1.1209682014 -26.66343035
theta -890.0900345 -26.66343035 823.25294163


The difference between the Wald and profile CL's for parameter PHI2 are remarkable, especially for the upper 95% and 99% limits.

Output 5.6.8: Confidence Limits

PROC NLP: Nonlinear Maximization

Wald and PL Confidence Limits
N Parameter Estimate Alpha Profile Likelihood Confidence
Limits
Wald Confidence Limits
1 sig 108.382730 0.500000 91.811562 141.564605 86.412311 130.353149
1 sig . 0.100000 76.502373 . 54.804268 161.961192
1 sig . 0.050000 72.215845 . 44.540054 172.225405
1 sig . 0.010000 64.262384 . 24.479232 192.286228
2 c 2.711477 0.500000 2.139297 3.704052 1.997355 3.425599
2 c . 0.100000 1.574162 9.250072 0.969973 4.452981
2 c . 0.050000 1.424853 19.516224 0.636347 4.786607
2 c . 0.010000 1.163096 19.540738 -0.015706 5.438660
3 theta 122.025944 0.500000 91.027145 135.095454 102.673191 141.378698
3 theta . 0.100000 . 141.833769 74.831088 142.985700
3 theta . 0.050000 . 142.512603 65.789804 142.985700
3 theta . 0.010000 . 142.967407 48.119128 142.985700
