Custom 2" Visual Back showing F6.3 FR	2" Visual Back	front view of 2" visual back
rear view of 2" visual back	another view of 2" back	another view showing FR threaded into the rear of the visual back
Optimal setup for Larger SCTs: Nikon F2+Lumicon NEG+2" visual back+f6.3 FR	another view	view with ruler showing the 4" total length from focal to FR.
Similar setup but ready for smaller SCTs, by using a 2" barrel adapter, including C9.25 for which this would be optimal	another view but with f6.3 FR attached	Another view showing individual components
another view	View of 2" diagonal and shortened 2" barrel.	2" diagonal inserted into 2" Back. Note the F6.3 reducer threaded into the visual back.
Camera side view of Lumicon NEG	Note large prism. Should be perfect for C-9.25	Note: very compact size of the NEG
Scope side of NEG	Custom 50mm finder. It will accept any 1.25" EP.
